Tilt Sensors (Inclinometers)
Inclinometers, also called tilt sensors, are designed to measure the angle of an object with respect to the force of gravity. These tilt or level meters determine pitch and/or roll angle and output these values via the appropriate electrical interface. Inclinometers are easy to integrate into an application because there is no need for mechanical linkages other than just the installation itself – a real advantage for design engineers. Available as single (up to 360°) or dual axis (up to +/- 90°) outputs, inclinometers are offered in a variety of electrical interfaces and housings which can withstand high pressure wash down or rated for hazardous environments.
Tilt Sensors (Inclinometers)
AKS - CANbus
POSITAL AKS inclinometers provide smooth data in dynamic environments...
ACS - Modubs RTU
POSITAL ACS Modbus inclinometers are ideal for solar tracking....
P603
The P603 is an affordable, durable, high-accuracy tilt sensor designed for....
S623
The 350bar S623 tilt sensor is an affordable, durable, high-accuracy sensor designed...
G603
The G603 is CSA approved and intrinscially safe for use in potentially explosive gas/vapour atmospheres....
X603
The X603 is ATEX, IECEx approved and intrinscially safe for use in potentially explosive gas/vapour atmospheres....
E603
The E603 is ATEX, IECEx approved and intrinscially safe for use in potentially explosive dust and gas/vapour atmospheres....
M603
The intrinsically safe M603is ATEX and IECEx approved for use in potentially explosive gas/vapour, dust atmospheres and mining...
Previous
Next
Read more about Tilt Sensors (Inclinometers)
Application Note: Ethernet Protocols for Industrial Automation Sensors
Industrial Ethernet protocols are playing a growing role in automation, as they offer a number of advantages over traditional fieldbus protocols such as CANopen and PROFIBUS. Industrial Ethernet protocols are based on standard Ethernet technology, which provides a number of benefits, including:
Analog Sensors – Now monitored (easily) in the Cloud
The Trumeter IoT Gateway is a device that allows you to connect your analog sensors to the internet for remote monitoring and data collection through the Trumeter Cloud platform. It is a plug-and-play device that supports up to four analog inputs and includes free access to the Trumeter Cloud dashboard.
Technical Note: Intrinsically Safe vs. Inherently Safe Sensors
Intrinsically safe (IS) sensors are designed to operate safely in hazardous areas where there is a risk of explosion. IS sensors limit the amount of electrical and thermal energy that can be released in the event of a fault, to a level below that which is capable of igniting flammable gases, vapors, or dust.
