POSITAL ACS – ATEX

“POSITAL has extended its TILTIX family of inclinometers (tilt sensors) to include explosion-proof
models designed to operate safely in environments
that contain potentially dangerous levels of explosive dust or gases. These devices have been certified in compliance with IECEx and ATEX directives and are suitable for use in mines, oil and gas
facilities, agricultural applications, chemical plants,
woodworking factories and milling operations.”

• Single or dual axis

• Zone 1/21 Mining or Oil and Gas

• Analog, Serial, CANopen & J1939 interfaces

• Aluminum and Stainless Steel Housing Options

Call to see if this sensor is right for your application! 856 727 9500


AKS – CANbus

POSITAL AKS inclinometers provide smooth data in dynamic environments

• Single or dual axis

• 360° (single), +/- 80° (dual)

• CANopen, SAE J1939 interface

• Ideal for dynamic applications

Call to see if this sensor is right for your application! 856 727 9500


Positek P500

The Positek P500 provides high resolution angle feedback

• 35mm diameter body

• Analog voltage and current outputs

• Up to 0.1% linearity

• 16-160 deg range; for <16 deg see P502

Call to see if this sensor is right for your application! 856 727 9500


Positek E500

CSA rated rotary sensor for gas and vapor environements

• ATEX/IECEx for gas/vapor and dust

• 0.5-9.5V or 4-20mA outputs

• ATEX variants of P502 & P505 available

• Up to 160 deg range

Call to see if this sensor is right for your application! 856 727 9500


Positek X500

ATEX rated rotary sensor for gas and oil applications

• ATEX/IECE: Ex II 1G; Ex ia IIC T4 GA

• 0.5-9.5V or 4-20mA outputs

• ATEX variants of P502, P505 and P520 available

• Up to 160 deg range

Call to see if this sensor is right for your application! 856 727 9500


POSITAL UCE/OCE

POSITAL explosion-proof roatry encoders are designed to operate safely in environments that contain potentially dangerous levels of explosive dust or gases. These devices have been certified in compliance with IECEx and ATEX directives and are suitable for use in mines, oil and gas facilities, agricultural applications, chemical plants, woodworking factories and milling operations.

• ATEX/IECEx rated

• Ethernet, SSI, CAN and Analog outputs

• Optional stainless steel housings

• Oil, gas, grain, and mining applications

Call to see if this sensor is right for your application! 856 727 9500


Positek P505

The Positek P505 provides high accuracy rotary positioning in the tighest of spaces

• 19mm diameter body

• Analog voltage and current outputs

• 0.25% linearity

• Measure up to 160 deg range

Call to see if this sensor is right for your application! 856 727 9500


Positek G500

CSA rated rotary sensor for oil and gas applications

• CSA rated for gas/vapor

• 0.5-9.5V or 4-20mA outputs

• ATEX variants of P502, P505 and P520 available

• Up to 160 deg range

Call to see if this sensor is right for your application! 856 727 9500


Positek P501

The Positek P501 provides high accuracy rotary positioning in the tighest of spaces

• 28.3mm diameter body

• Analog voltage and current outputs

• Up to 0.1% linearity

• Measure up to 140 deg range

Call to see if this sensor is right for your application! 856 727 9500


Positek S520

The Positek S520 rotary sensor is designed for Marine and Subsea applications

• Subsea encoder to 350Bar, 5000 psi

• Analog voltage and current outputs

• Up to 0.1% linearity

• Measure up to 100 deg range

Call to see if this sensor is right for your application! 856 727 9500
